Specification sheet
| Motorcycle Model | LF250-8(172FMM-2B/NBS250) |
|---|---|
| Dimension (L×W×H mm) | 2170×880×1150 |
| Wheelbase (mm) | 1440 |
| Ground Clearance (mm) | 190 |
| Net Weight (kg) | 167 |
| Seat Height (mm) | 715 |
| Fuel Tank Capacity (L) | 13 |
| Engine Type | vertical single-cylinder, oil-cooled, four-stroke |
| Bore×Stroke (mm) | 72.0×61.2 |
| Displacement (mL) | 249 |
| Compression Ratio | 9.8:1 |
| Max. Power (Kw@rpm) | 15.0@7800 |
| Max. Torque (N.m@rpm) | 20.0@6000 |
| Start | electric |
| Transmission | 6-gears, hand-clutched |
| Brake (front/rear) | disc/disc |
| Wheel | Al-alloy |
| Tire (front/rear) | 120/80-18/150/80-15 |
| Max. Speed (km/h) | 115 |
| Economical Fuel Consumption (km/L) | ≥40.00 |
| Fuel Supply System | electronic fuel injection |
Same platform
| Model | CC |
|---|---|
| C-MAN3 | 125 |
| CRUISER | 125 |
| K19 | 150 |
| K19 | 198 |
| K29 | 250 |
