Specification sheet
| Motorcycle Model | LF200-14F (NBF200) |
|---|---|
| Dimension (L×W×H mm) | 2230×910×1090 |
| Wheelbase (mm) | 1500 |
| Ground Clearance (mm) | 145 |
| Net Weight (kg) | 160 |
| Seat Height (mm) | 710 |
| Fuel Tank Capacity (L) | 14 |
| Engine Type | vertical Single-cylinder, water-cooled, four-stroke |
| Bore×Stroke (mm) | 65.5×58.8 |
| Displacement (mL) | 198 |
| Compression Ratio | 11.0:1 |
| Max. Power (Kw@rpm) | 12.5@8000 |
| Max. Torque (N.m@rpm) | 17.0@6500 |
| Start | electric |
| Transmission | 6-gears, hand-clutched |
| Brake (front/rear) | disc/drum |
| Wheel | Al-alloy |
| Tire (front/rear) | 110/90-16/130/90-15 |
| Max. Speed (km/h) | 110 |
| Economical Fuel Consumption (km/L) | ≥43.5 |
Same platform
| Model | CC |
|---|---|
| C-MAN3 | 125 |
| CRUISER | 125 |
| K19 | 150 |
| K29 | 250 |
| LF125-7 | 125 |
