Specification sheet
| Three-Wheeler Model | LF1200DZH-KD |
|---|---|
| Dimension (L×W×H mm) | 2960×1060×1780 |
| Wheelbase (mm) | 1935 |
| Min.Ground Clearance | 130 |
| Net Weight (kg) | 290 |
| Electric Motor Model | CNPW4-1200 |
| Motor Power(W) | 1200 |
| Rated Current(A) | 21 |
| Rated Speed(rpm) | 3000 |
| Insulation Grade | E |
| Max. Speed (km/h) | 30 |
| Front Tire Size and Air Pressure | 4.00-12/280Kpa |
| Rear Tire Size and Air Pressure | 4.00-12/280Kpa |
| Climbing Ability | 25° |
| Start Performance | ≦15s |
| Brake Performance | ≦7m/30km/h |
| Mileage(km) | 50 |
Same platform
| Model | CC |
|---|---|
| LF1200DZH-KD | |
| LF150ZH-3 | 149 |
| LF200ZH-2 | 197 |
| LF200ZH-3A | 197 |
| LF200ZH-3R | 197 |
