Specification sheet
| Motorcycle Model | LF150GY-4D/LF200GY-4D (NBS150/CG200) |
|---|---|
| Dimension (L×W×H mm) | 2090×820×1120 |
| Wheelbase (mm) | 1355 |
| Ground Clearance (mm) | 240 |
| Net Weight (kg) | 132 |
| Seat Height (mm) | 845 |
| Fuel Tank Capacity (L) | 11.5 |
| Engine Type | vertical single-cylinder, air-cooled, four-stroke |
| Bore×Stroke (mm) | 57.3×57.8/ 63.5×62.2 |
| Displacement (mL) | 149/ 197 |
| Compression Ratio | 9.2:1/ 9.0:1 |
| Max. Power (Kw@rpm) | 9.2@8500/11.5@8000 |
| Max. Torque (N.m@rpm) | 11.5@6500/13.8@6500 |
| Start | electric/kick start |
| Transmission | 5-gears, hand-clutched |
| Brake (front/rear) | disc/drum |
| Wheel | spoke |
| Tire (front/rear) | 90/90-19, 110/90-17 |
| Max. Speed (km/h) | 98/105 |
| Economical Fuel Consumption (km/L) | ≥43.5 |
Same platform
| Model | CC |
|---|---|
| LF250GY-3 | 250 |
| LF70GY-3 | 72 |
| X-PECT 200 | 200 |
| X-PECT 250 | 250 |
| X-TRIAL | 200 |
